Source Country Codes (CCs)

#	Key	CCs		Name	Total		Max	Avg
01			KR	Korea, The Republic of	476.51 MB	20.86 %	29.72 KB/s	5.52 KB/s
02			CN	China	442.23 MB	19.36 %	18.66 KB/s	5.12 KB/s
03			RU	Russian Federation	332.14 MB	14.54 %	19.45 KB/s	3.84 KB/s
04			US	United States of America	214.70 MB	9.40 %	5.99 KB/s	2.48 KB/s
05			PK	Pakistan	193.69 MB	8.48 %	5.90 KB/s	2.24 KB/s
06			NL	Netherlands	134.14 MB	5.87 %	19.35 KB/s	1.55 KB/s
07			BG	Bulgaria	54.07 MB	2.37 %	5.81 KB/s	625.78 B/s
08			SG	Singapore	52.93 MB	2.32 %	800.69 B/s	612.61 B/s
09			BO	Bolivia (Plurinational State of)	48.87 MB	2.14 %	8.00 KB/s	565.68 B/s
10			DE	Germany	35.94 MB	1.57 %	9.51 KB/s	415.93 B/s
11		Others			299.52 MB	13.11 %	18.22 KB/s	3.47 KB/s

Source AS Numbers (ASNs)

#	Key	ASNs	Name	CC		Total		Max	Avg
01		4766	KIXS-AS-KR Korea Telecom		KR	340.99 MB	14.92 %	21.91 KB/s	3.95 KB/s
02		4134	CHINANET-BACKBONE No.31,Jin-rong...		CN	267.00 MB	11.69 %	16.33 KB/s	3.09 KB/s
03		8359	MTS		RU	246.35 MB	10.78 %	3.89 KB/s	2.85 KB/s
04		23888	NTC-AS-AP National Telecommunica...		PK	191.82 MB	8.40 %	5.89 KB/s	2.22 KB/s
05		4837	CHINA169-BACKBONE CHINA UNICOM C...		CN	136.08 MB	5.96 %	13.85 KB/s	1.57 KB/s
06		49870	AS49870-BV		NL	118.72 MB	5.20 %	19.14 KB/s	1.37 KB/s
07		23584	HYROADPUSAN-AS-KR PUSAN CABLE TV...		KR	100.05 MB	4.38 %	7.21 KB/s	1.16 KB/s
08		16509	AMAZON-02		US	80.80 MB	3.54 %	1.20 KB/s	935.18 B/s
09		27839	Comteco Ltda		BO	42.04 MB	1.84 %	916.82 B/s	486.55 B/s
10		14618	AMAZON-AES		US	32.82 MB	1.44 %	570.20 B/s	379.91 B/s
11		Others				728.07 MB	31.87 %	33.49 KB/s	8.43 KB/s

Protocols

#	Key	Protocol	Total		Max	Avg
01		TCP	2.06 GB	90.00 %	47.39 KB/s	23.80 KB/s
02		ICMP	188.26 MB	8.24 %	2.52 KB/s	2.18 KB/s
03		UDP	40.23 MB	1.76 %	2.63 KB/s	465.67 B/s
04		Others	0.00 B	0.00 %	0.00 B/s	0.00 B/s

Destination TCP Ports

#	Key	Port	Name	Total		Max	Avg
01		23	TELNET	1.78 GB	86.49 %	44.48 KB/s	20.58 KB/s
02		445	Microsoft-DS Active Directory	29.27 MB	1.42 %	488.68 B/s	338.76 B/s
03		22	SSH (Secure Shell)	24.91 MB	1.21 %	524.17 B/s	288.27 B/s
04		62130	N/A	15.19 MB	0.74 %	1.81 KB/s	175.80 B/s
05		56348	N/A	15.14 MB	0.74 %	1.81 KB/s	175.27 B/s
06		80	HTTP (Hypertext Transfer Protocol)	14.59 MB	0.71 %	1.24 KB/s	168.89 B/s
07		3389	RDP (Microsoft Terminal Server)	7.66 MB	0.37 %	335.35 B/s	88.67 B/s
08		443	HTTPS (Hypertext Transfer Protocol over TLS/SSL)	6.05 MB	0.29 %	206.53 B/s	70.01 B/s
09		8080	HTTP Proxy	4.32 MB	0.21 %	236.81 B/s	50.00 B/s
10		1433	Microsoft SQL Server	1.89 MB	0.09 %	46.76 B/s	21.85 B/s
11	---	139	NETBIOS Session Service	1.81 MB	0.09 %	197.51 B/s	20.89 B/s
12	---	21	FTP (File Transfer Protocol - control)	1.46 MB	0.07 %	237.65 B/s	16.86 B/s
13	---	8000	N/A	1.22 MB	0.06 %	225.22 B/s	14.15 B/s
14	---	3306	MySQL	1.19 MB	0.06 %	54.01 B/s	13.80 B/s
15	---	10000	Webmin / BackupExec	1.06 MB	0.05 %	88.51 B/s	12.32 B/s
16	---	26	N/A	919.47 KB	0.04 %	70.70 B/s	10.64 B/s
17	---	8443	Apache Tomcat	814.91 KB	0.04 %	27.20 B/s	9.43 B/s
18	---	5000	UPnP	813.85 KB	0.04 %	106.51 B/s	9.42 B/s
19	---	2222	N/A	686.55 KB	0.03 %	21.39 B/s	7.95 B/s
20	---	995	POP3S (POP version 3 over TLS/SSL)	674.49 KB	0.03 %	58.03 B/s	7.81 B/s
21	---	50802	N/A	626.41 KB	0.03 %	13.66 B/s	7.25 B/s
22	---	81	N/A	582.69 KB	0.03 %	23.24 B/s	6.74 B/s
23	---	554	RTSP (Real Time Stream Control Protocol)	566.98 KB	0.03 %	75.60 B/s	6.56 B/s
24	---	993	IMAPS (IMAP over TLS/SSL)	543.26 KB	0.03 %	53.90 B/s	6.29 B/s
25	---	135	Microsoft RCP	531.36 KB	0.03 %	34.83 B/s	6.15 B/s
26	---	3128	HTTP Proxy	500.11 KB	0.02 %	25.41 B/s	5.79 B/s
27	---	7547	TR-069 (abused by Mirai/IoT botnets)	487.48 KB	0.02 %	22.38 B/s	5.64 B/s
28	---	4444	Blaster	456.62 KB	0.02 %	50.84 B/s	5.28 B/s
29	---	143	IMAP (Internet Message Access Protocol)	450.14 KB	0.02 %	41.11 B/s	5.21 B/s
30	---	6379	Redis	438.74 KB	0.02 %	13.68 B/s	5.08 B/s
31	---	Others		142.96 MB	6.95 %	2.28 KB/s	1.65 KB/s

Destination UDP Ports

#	Key	Port	Name	Total		Max	Avg
01		5060	SIP (Session Initiation Protocol)	17.82 MB	44.30 %	1.85 KB/s	206.31 B/s
02		80	HTTP (Hypertext Transfer Protocol)	3.33 MB	8.28 %	143.55 B/s	38.56 B/s
03		443	N/A	1.47 MB	3.66 %	113.61 B/s	17.04 B/s
04		500	ISAKMP	1.12 MB	2.79 %	205.60 B/s	13.01 B/s
05		3702	WS-Discovery	869.04 KB	2.16 %	68.66 B/s	10.06 B/s
06		123	NTP (Network Time Protocol)	766.04 KB	1.90 %	35.56 B/s	8.87 B/s
07		4614	N/A	690.41 KB	1.72 %	232.23 B/s	7.99 B/s
08		161	SNMP (Simple Network Management Protocol)	686.08 KB	1.71 %	64.83 B/s	7.94 B/s
09		53	DNS (Domain Name System)	625.24 KB	1.55 %	82.70 B/s	7.24 B/s
10		1900	SSDP	559.69 KB	1.39 %	35.16 B/s	6.48 B/s
11	---	5070	VTSAS (VersaTrans Server Agent Service)	425.54 KB	1.06 %	164.45 B/s	4.93 B/s
12	---	5080	N/A	349.71 KB	0.87 %	46.60 B/s	4.05 B/s
13	---	5353	mDNS (Multicast DNS)	330.56 KB	0.82 %	12.43 B/s	3.83 B/s
14	---	6881	BitTorrent	308.47 KB	0.77 %	16.21 B/s	3.57 B/s
15	---	1434	Microsoft SQL Monitor	280.60 KB	0.70 %	10.18 B/s	3.25 B/s
16	---	4500	ipsec-nat-t (ipsec-msft, IPsec NAT-Traversal)	268.56 KB	0.67 %	12.01 B/s	3.11 B/s
17	---	8081	N/A	240.25 KB	0.60 %	6.46 B/s	2.78 B/s
18	---	1027	N/A	234.94 KB	0.58 %	5.88 B/s	2.72 B/s
19	---	8080	N/A	234.71 KB	0.58 %	8.71 B/s	2.72 B/s
20	---	4000	N/A	233.24 KB	0.58 %	5.08 B/s	2.70 B/s
21	---	8000	N/A	233.16 KB	0.58 %	5.08 B/s	2.70 B/s
22	---	5071	N/A	228.65 KB	0.57 %	36.76 B/s	2.65 B/s
23	---	8083	N/A	228.62 KB	0.57 %	6.43 B/s	2.65 B/s
24	---	30301	BitTorrent	222.74 KB	0.55 %	9.79 B/s	2.58 B/s
25	---	11211	Memcached	220.65 KB	0.55 %	12.37 B/s	2.55 B/s
26	---	8082	N/A	219.16 KB	0.54 %	4.42 B/s	2.54 B/s
27	---	53413	Netis Router Backdoor	197.82 KB	0.49 %	159.58 B/s	2.29 B/s
28	---	6500	N/A	188.05 KB	0.47 %	626.28 B/s	2.18 B/s
29	---	389	LDAP (Lightweight Directory Access)	181.42 KB	0.45 %	24.71 B/s	2.10 B/s
30	---	137	NETBIOS Name Service	178.90 KB	0.44 %	22.02 B/s	2.07 B/s
31	---	Others		7.28 MB	18.09 %	554.62 B/s	84.25 B/s

Source Operating Systems (Windows)

#	Key	Operating System	Total		Max	Avg
01		Windows-2000-RFC1323/Windows-XP-RFC1323	13.95 MB	42.01 %	435.00 B/s	161.41 B/s
02		Windows-Vista	8.96 MB	26.98 %	234.40 B/s	103.66 B/s
03		Windows-XP-SP1/Windows-2000-SP2+	6.61 MB	19.92 %	297.33 B/s	76.56 B/s
04		Windows-XP-SP1/Windows-2000-SP4	2.71 MB	8.17 %	308.14 B/s	31.38 B/s
05		Windows-2000/Windows-XP	945.87 KB	2.85 %	196.04 B/s	10.95 B/s
06		Windows-XP-SP1/Windows-2000-SP3	22.75 KB	0.07 %	7.70 B/s	0.26 B/s
07		Windows-98-lowTTL	1.31 KB	0.00 %	3.09 B/s	0.02 B/s
08		Windows-NT-4.0	949.90 B	0.00 %	0.93 B/s	0.01 B/s
09		Windows-XP-RFC1323	421.50 B	0.00 %	0.64 B/s	0.00 B/s
10		Windows-98	124.76 B	0.00 %	0.07 B/s	0.00 B/s
11		other-Windows	98.66 B	0.00 %	0.08 B/s	0.00 B/s

Source Operating Systems (Other Platforms)

#	Key	Operating System	Total		Max	Avg
01		unknown	1.76 GB	87.03 %	41.70 KB/s	20.38 KB/s
02		Linux	228.28 MB	11.28 %	27.46 KB/s	2.64 KB/s
03		undefined	33.99 MB	1.68 %	3.69 KB/s	393.46 B/s
04		Eagle	60.60 KB	0.00 %	2.67 B/s	0.70 B/s
05		NMAP	27.70 KB	0.00 %	8.62 B/s	0.32 B/s
06		SunOS	765.09 B	0.00 %	0.15 B/s	0.01 B/s
07		Solaris	751.80 B	0.00 %	1.41 B/s	0.01 B/s
08		ExtremeWare-4.x	469.49 B	0.00 %	0.17 B/s	0.01 B/s
09		NAST	47.21 B	0.00 %	0.07 B/s	0.00 B/s
10		FreeBSD	46.76 B	0.00 %	0.15 B/s	0.00 B/s
11		Others	17.88 B	0.00 %	0.04 B/s	0.00 B/s

Observations:

1. Each image above contains a STACK AREA graphic, which means that each data set of the graphic is stacked on top of the previous one.


2. Lists of known TCP/UDP ports and associated service names can be found at the following documents:
   • Port Numbers, from IANA.
   • List of TCP and UDP port numbers, from The Wikipedia.
   • Common Ports, from packetlife.net.


3. A list of known Country Codes can be found at IANA. The country code "XX" stands for network flows that could not be associated with any country code, for example, flows from private networks.
