Source Country Codes (CCs)

#	Key	CCs		Name	Total		Max	Avg
01			NL	Netherlands	804.81 MB	31.11 %	25.06 KB/s	9.31 KB/s
02			CN	China	503.65 MB	19.47 %	13.44 KB/s	5.83 KB/s
03			KR	Korea, The Republic of	367.24 MB	14.19 %	13.93 KB/s	4.25 KB/s
04			US	United States of America	261.72 MB	10.12 %	9.12 KB/s	3.03 KB/s
05			RU	Russian Federation	227.99 MB	8.81 %	5.36 KB/s	2.64 KB/s
06			BG	Bulgaria	71.39 MB	2.76 %	3.36 KB/s	826.28 B/s
07			PK	Pakistan	63.05 MB	2.44 %	3.03 KB/s	729.69 B/s
08			KH	Cambodia	35.05 MB	1.35 %	860.28 B/s	405.69 B/s
09			BR	Brazil	27.97 MB	1.08 %	3.88 KB/s	323.67 B/s
10			SG	Singapore	22.78 MB	0.88 %	355.82 B/s	263.71 B/s
11		Others			201.57 MB	7.79 %	14.90 KB/s	2.33 KB/s

Source AS Numbers (ASNs)

#	Key	ASNs	Name	CC		Total		Max	Avg
01		49870	AS49870-BV		NL	793.04 MB	30.65 %	24.97 KB/s	9.18 KB/s
02		4837	CHINA169-BACKBONE CHINA UNICOM C...		CN	376.98 MB	14.57 %	11.86 KB/s	4.36 KB/s
03		4766	KIXS-AS-KR Korea Telecom		KR	185.80 MB	7.18 %	9.96 KB/s	2.15 KB/s
04		7623	HCNGYEONGBUK-AS-KR Gyeongbuk Cab...		KR	146.88 MB	5.68 %	11.45 KB/s	1.70 KB/s
05		60904	ATSTEL-AS		RU	110.77 MB	4.28 %	1.87 KB/s	1.28 KB/s
06		4134	CHINANET-BACKBONE No.31,Jin-rong...		CN	96.43 MB	3.73 %	1.78 KB/s	1.12 KB/s
07		16509	AMAZON-02		US	69.36 MB	2.68 %	895.45 B/s	802.77 B/s
08		23888	NTC-AS-AP National Telecommunica...		PK	62.84 MB	2.43 %	3.03 KB/s	727.36 B/s
09		211252	AS_DELIS		US	45.74 MB	1.77 %	3.07 KB/s	529.34 B/s
10		11878	TZULO		US	43.06 MB	1.66 %	6.28 KB/s	498.37 B/s
11		Others				656.32 MB	25.37 %	20.65 KB/s	7.60 KB/s

Protocols

#	Key	Protocol	Total		Max	Avg
01		TCP	2.35 GB	90.81 %	47.53 KB/s	27.19 KB/s
02		ICMP	146.12 MB	5.65 %	1.84 KB/s	1.69 KB/s
03		UDP	91.77 MB	3.55 %	2.40 KB/s	1.06 KB/s
04		Others	0.00 B	0.00 %	0.00 B/s	0.00 B/s

Destination TCP Ports

#	Key	Port	Name	Total		Max	Avg
01		23	TELNET	2.01 GB	85.72 %	40.48 KB/s	23.31 KB/s
02		3389	RDP (Microsoft Terminal Server)	81.62 MB	3.47 %	12.62 KB/s	944.69 B/s
03		445	Microsoft-DS Active Directory	47.93 MB	2.04 %	827.93 B/s	554.71 B/s
04		22	SSH (Secure Shell)	37.74 MB	1.61 %	772.13 B/s	436.81 B/s
05		80	HTTP (Hypertext Transfer Protocol)	15.88 MB	0.68 %	925.91 B/s	183.77 B/s
06		62130	N/A	11.72 MB	0.50 %	1.03 KB/s	135.69 B/s
07		56348	N/A	11.72 MB	0.50 %	1.05 KB/s	135.67 B/s
08		443	HTTPS (Hypertext Transfer Protocol over TLS/SSL)	5.82 MB	0.25 %	674.21 B/s	67.30 B/s
09		8080	HTTP Proxy	3.74 MB	0.16 %	231.59 B/s	43.24 B/s
10		21	FTP (File Transfer Protocol - control)	1.69 MB	0.07 %	182.86 B/s	19.60 B/s
11	---	3306	MySQL	1.47 MB	0.06 %	593.25 B/s	16.97 B/s
12	---	139	NETBIOS Session Service	1.46 MB	0.06 %	222.10 B/s	16.93 B/s
13	---	1433	Microsoft SQL Server	1.46 MB	0.06 %	61.06 B/s	16.89 B/s
14	---	8000	N/A	1.22 MB	0.05 %	79.69 B/s	14.14 B/s
15	---	5000	UPnP	945.82 KB	0.04 %	96.89 B/s	10.95 B/s
16	---	3372	N/A	632.62 KB	0.03 %	98.93 B/s	7.32 B/s
17	---	110	POP3 (Post Office Protocol - version 3)	619.72 KB	0.03 %	111.70 B/s	7.17 B/s
18	---	8443	Apache Tomcat	608.38 KB	0.03 %	42.73 B/s	7.04 B/s
19	---	135	Microsoft RCP	607.42 KB	0.03 %	138.51 B/s	7.03 B/s
20	---	8728	Mikrotik API	596.92 KB	0.03 %	10.11 B/s	6.91 B/s
21	---	2222	N/A	577.02 KB	0.02 %	49.97 B/s	6.68 B/s
22	---	995	POP3S (POP version 3 over TLS/SSL)	559.65 KB	0.02 %	78.81 B/s	6.48 B/s
23	---	554	RTSP (Real Time Stream Control Protocol)	532.03 KB	0.02 %	77.27 B/s	6.16 B/s
24	---	993	IMAPS (IMAP over TLS/SSL)	511.96 KB	0.02 %	60.49 B/s	5.93 B/s
25	---	6379	Redis	503.84 KB	0.02 %	31.84 B/s	5.83 B/s
26	---	10000	Webmin / BackupExec	493.87 KB	0.02 %	76.95 B/s	5.72 B/s
27	---	2375	Docker REST API	489.41 KB	0.02 %	49.14 B/s	5.66 B/s
28	---	465	SMTP over SSL	485.36 KB	0.02 %	47.71 B/s	5.62 B/s
29	---	7547	TR-069 (abused by Mirai/IoT botnets)	465.17 KB	0.02 %	43.58 B/s	5.38 B/s
30	---	4444	Blaster	452.81 KB	0.02 %	50.38 B/s	5.24 B/s
31	---	Others		102.98 MB	4.38 %	4.62 KB/s	1.19 KB/s

Destination UDP Ports

#	Key	Port	Name	Total		Max	Avg
01		5060	SIP (Session Initiation Protocol)	73.25 MB	79.82 %	1.58 KB/s	847.76 B/s
02		4614	N/A	1.85 MB	2.01 %	171.41 B/s	21.37 B/s
03		500	ISAKMP	1.48 MB	1.61 %	348.40 B/s	17.10 B/s
04		3702	WS-Discovery	1.06 MB	1.16 %	70.07 B/s	12.28 B/s
05		123	NTP (Network Time Protocol)	972.61 KB	1.06 %	65.34 B/s	11.26 B/s
06		161	SNMP (Simple Network Management Protocol)	582.56 KB	0.63 %	86.84 B/s	6.74 B/s
07		1900	SSDP	533.79 KB	0.58 %	21.91 B/s	6.18 B/s
08		6500	N/A	509.08 KB	0.55 %	1.25 KB/s	5.89 B/s
09		80	HTTP (Hypertext Transfer Protocol)	457.95 KB	0.50 %	83.86 B/s	5.30 B/s
10		443	N/A	443.94 KB	0.48 %	108.36 B/s	5.14 B/s
11	---	53	DNS (Domain Name System)	372.48 KB	0.41 %	55.50 B/s	4.31 B/s
12	---	5353	mDNS (Multicast DNS)	324.08 KB	0.35 %	77.84 B/s	3.75 B/s
13	---	4500	ipsec-nat-t (ipsec-msft, IPsec NAT-Traversal)	322.87 KB	0.35 %	89.12 B/s	3.74 B/s
14	---	5070	VTSAS (VersaTrans Server Agent Service)	305.61 KB	0.33 %	145.64 B/s	3.54 B/s
15	---	6881	BitTorrent	300.15 KB	0.33 %	22.17 B/s	3.47 B/s
16	---	9034	N/A	275.69 KB	0.30 %	15.59 B/s	3.19 B/s
17	---	53413	Netis Router Backdoor	274.81 KB	0.30 %	195.22 B/s	3.18 B/s
18	---	1434	Microsoft SQL Monitor	269.35 KB	0.29 %	33.79 B/s	3.12 B/s
19	---	8080	N/A	240.60 KB	0.26 %	14.24 B/s	2.78 B/s
20	---	8082	N/A	235.74 KB	0.26 %	5.78 B/s	2.73 B/s
21	---	30301	BitTorrent	234.57 KB	0.26 %	7.68 B/s	2.71 B/s
22	---	8081	N/A	234.47 KB	0.26 %	18.08 B/s	2.71 B/s
23	---	8000	N/A	232.99 KB	0.25 %	7.07 B/s	2.70 B/s
24	---	8083	N/A	231.95 KB	0.25 %	5.47 B/s	2.68 B/s
25	---	4000	N/A	227.50 KB	0.25 %	4.19 B/s	2.63 B/s
26	---	1027	N/A	225.07 KB	0.25 %	4.60 B/s	2.60 B/s
27	---	11211	Memcached	214.56 KB	0.23 %	9.55 B/s	2.48 B/s
28	---	137	NETBIOS Name Service	207.33 KB	0.23 %	63.64 B/s	2.40 B/s
29	---	389	LDAP (Lightweight Directory Access)	150.05 KB	0.16 %	23.52 B/s	1.74 B/s
30	---	5062	N/A	110.72 KB	0.12 %	99.01 B/s	1.28 B/s
31	---	Others		5.65 MB	6.15 %	540.74 B/s	65.37 B/s

Source Operating Systems (Windows)

#	Key	Operating System	Total		Max	Avg
01		Windows-XP-SP1/Windows-2000-SP2+	18.54 MB	40.97 %	329.54 B/s	214.61 B/s
02		Windows-2000-RFC1323/Windows-XP-RFC1323	16.12 MB	35.62 %	507.81 B/s	186.56 B/s
03		Windows-Vista	8.87 MB	19.60 %	240.41 B/s	102.69 B/s
04		Windows-XP-SP1/Windows-2000-SP4	935.62 KB	2.07 %	45.40 B/s	10.83 B/s
05		Windows-XP-SP1/Windows-2000-SP3	426.24 KB	0.94 %	231.12 B/s	4.93 B/s
06		Windows-2000/Windows-XP	355.94 KB	0.79 %	52.79 B/s	4.12 B/s
07		Windows-XP-RFC1323	2.67 KB	0.01 %	1.46 B/s	0.03 B/s
08		Windows-98-lowTTL	320.08 B	0.00 %	0.19 B/s	0.00 B/s
09		Windows-NT-4.0	120.18 B	0.00 %	0.13 B/s	0.00 B/s
10		Windows-.NET	88.55 B	0.00 %	0.22 B/s	0.00 B/s
11		other-Windows	11.79 B	0.00 %	0.02 B/s	0.00 B/s

Source Operating Systems (Other Platforms)

#	Key	Operating System	Total		Max	Avg
01		unknown	2.01 GB	87.28 %	44.50 KB/s	23.27 KB/s
02		Linux	269.37 MB	11.69 %	7.33 KB/s	3.12 KB/s
03		undefined	23.51 MB	1.02 %	2.07 KB/s	272.11 B/s
04		NMAP	159.17 KB	0.01 %	34.39 B/s	1.84 B/s
05		Eagle	122.22 KB	0.01 %	13.61 B/s	1.41 B/s
06		IRIX-6.2-6.5	109.20 B	0.00 %	0.15 B/s	0.00 B/s
07		SunOS	52.42 B	0.00 %	0.07 B/s	0.00 B/s
08		ULTRIX-4.5	21.91 B	0.00 %	0.02 B/s	0.00 B/s
09		NAST	6.41 B	0.00 %	0.01 B/s	0.00 B/s
10		TOPS-20-7	5.67 B	0.00 %	0.02 B/s	0.00 B/s
11		Others	2.73 B	0.00 %	0.00 B/s	0.00 B/s

Observations:

1. Each image above contains a STACK AREA graphic, which means that each data set of the graphic is stacked on top of the previous one.


2. Lists of known TCP/UDP ports and associated service names can be found at the following documents:
   • Port Numbers, from IANA.
   • List of TCP and UDP port numbers, from The Wikipedia.
   • Common Ports, from packetlife.net.


3. A list of known Country Codes can be found at IANA. The country code "XX" stands for network flows that could not be associated with any country code, for example, flows from private networks.
