Source Country Codes (CCs)

#	Key	CCs		Name	Total		Max	Avg
01			CN	China	1.77 GB	43.49 %	26.60 KB/s	20.48 KB/s
02			RU	Russian Federation	317.90 MB	7.81 %	19.64 KB/s	3.68 KB/s
03			LY	Libya	301.07 MB	7.40 %	5.72 KB/s	3.48 KB/s
04			KR	Korea, The Republic of	224.88 MB	5.53 %	10.56 KB/s	2.60 KB/s
05			US	United States of America	216.50 MB	5.32 %	10.75 KB/s	2.51 KB/s
06			BG	Bulgaria	207.87 MB	5.11 %	6.66 KB/s	2.41 KB/s
07			LT	Lithuania	186.29 MB	4.58 %	7.49 KB/s	2.16 KB/s
08			VN	Viet Nam	178.89 MB	4.40 %	4.21 KB/s	2.07 KB/s
09			PK	Pakistan	161.79 MB	3.98 %	4.14 KB/s	1.87 KB/s
10			NL	Netherlands	93.82 MB	2.31 %	4.30 KB/s	1.09 KB/s
11		Others			410.23 MB	10.08 %	66.56 KB/s	4.75 KB/s

Source AS Numbers (ASNs)

#	Key	ASNs	Name	CC		Total		Max	Avg
01		4837	CHINA169-BACKBONE CHINA UNICOM C...		CN	1.16 GB	28.58 %	20.41 KB/s	13.46 KB/s
02		21003	GPTC-AS		LY	301.07 MB	7.40 %	5.72 KB/s	3.48 KB/s
03		209605	HOSTBALTIC		LT	186.07 MB	4.57 %	7.49 KB/s	2.15 KB/s
04		211252	AS_DELIS		US	181.49 MB	4.46 %	6.21 KB/s	2.10 KB/s
05		4134	CHINANET-BACKBONE No.31,Jin-rong...		CN	173.00 MB	4.25 %	3.08 KB/s	2.00 KB/s
06		18403	FPT-AS-AP FPT Telecom Company		VN	172.17 MB	4.23 %	4.10 KB/s	1.99 KB/s
07		23888	NTC-AS-AP National Telecommunica...		PK	159.13 MB	3.91 %	3.13 KB/s	1.84 KB/s
08		24547	CMNET-V4HEBEI-AS-AP Hebei Mobile...		CN	158.52 MB	3.90 %	3.15 KB/s	1.83 KB/s
09		56041	CMNET-ZHEJIANG-AP China Mobile c...		CN	136.14 MB	3.35 %	2.73 KB/s	1.58 KB/s
10		4766	KIXS-AS-KR Korea Telecom		KR	113.82 MB	2.80 %	10.27 KB/s	1.32 KB/s
11		Others				1.32 GB	32.56 %	110.31 KB/s	15.33 KB/s

Protocols

#	Key	Protocol	Total		Max	Avg
01		TCP	3.78 GB	92.94 %	58.16 KB/s	43.77 KB/s
02		UDP	159.36 MB	3.92 %	95.55 KB/s	1.84 KB/s
03		ICMP	127.96 MB	3.14 %	1.82 KB/s	1.48 KB/s
04		Others	0.00 B	0.00 %	0.00 B/s	0.00 B/s

Destination TCP Ports

#	Key	Port	Name	Total		Max	Avg
01		23	TELNET	3.07 GB	81.12 %	48.59 KB/s	35.51 KB/s
02		443	HTTPS (Hypertext Transfer Protocol over TLS/SSL)	455.73 MB	12.05 %	8.00 KB/s	5.27 KB/s
03		22	SSH (Secure Shell)	44.41 MB	1.17 %	1.16 KB/s	514.01 B/s
04		445	Microsoft-DS Active Directory	32.86 MB	0.87 %	808.20 B/s	380.29 B/s
05		3389	RDP (Microsoft Terminal Server)	11.93 MB	0.32 %	401.07 B/s	138.07 B/s
06		80	HTTP (Hypertext Transfer Protocol)	10.83 MB	0.29 %	635.56 B/s	125.34 B/s
07		8080	HTTP Proxy	2.85 MB	0.08 %	140.70 B/s	33.01 B/s
08		1433	Microsoft SQL Server	1.84 MB	0.05 %	52.86 B/s	21.31 B/s
09		5000	UPnP	1.59 MB	0.04 %	270.77 B/s	18.45 B/s
10		3306	MySQL	1.43 MB	0.04 %	63.46 B/s	16.51 B/s
11	---	139	NETBIOS Session Service	1.41 MB	0.04 %	109.33 B/s	16.31 B/s
12	---	5555	ADB (Android Debug Bridge)	1.05 MB	0.03 %	29.09 B/s	12.21 B/s
13	---	21	FTP (File Transfer Protocol - control)	912.94 KB	0.02 %	82.93 B/s	10.57 B/s
14	---	8000	N/A	675.24 KB	0.02 %	62.44 B/s	7.82 B/s
15	---	135	Microsoft RCP	649.92 KB	0.02 %	79.44 B/s	7.52 B/s
16	---	110	POP3 (Post Office Protocol - version 3)	634.06 KB	0.02 %	78.09 B/s	7.34 B/s
17	---	993	IMAPS (IMAP over TLS/SSL)	614.44 KB	0.02 %	65.86 B/s	7.11 B/s
18	---	2107	N/A	600.54 KB	0.02 %	285.01 B/s	6.95 B/s
19	---	6379	Redis	594.30 KB	0.02 %	17.65 B/s	6.88 B/s
20	---	465	SMTP over SSL	593.26 KB	0.02 %	50.55 B/s	6.87 B/s
21	---	995	POP3S (POP version 3 over TLS/SSL)	590.51 KB	0.02 %	62.06 B/s	6.83 B/s
22	---	2375	Docker REST API	529.29 KB	0.01 %	36.02 B/s	6.13 B/s
23	---	81	N/A	512.76 KB	0.01 %	32.28 B/s	5.93 B/s
24	---	554	RTSP (Real Time Stream Control Protocol)	511.28 KB	0.01 %	74.50 B/s	5.92 B/s
25	---	10000	Webmin / BackupExec	500.65 KB	0.01 %	52.05 B/s	5.79 B/s
26	---	7547	TR-069 (abused by Mirai/IoT botnets)	476.48 KB	0.01 %	20.79 B/s	5.51 B/s
27	---	143	IMAP (Internet Message Access Protocol)	453.46 KB	0.01 %	47.64 B/s	5.25 B/s
28	---	2376	Docker REST API (ssl)	435.13 KB	0.01 %	26.48 B/s	5.04 B/s
29	---	8291	Mikrotik Winbox	434.21 KB	0.01 %	38.06 B/s	5.03 B/s
30	---	3128	HTTP Proxy	409.61 KB	0.01 %	29.51 B/s	4.74 B/s
31	---	Others		138.06 MB	3.65 %	4.55 KB/s	1.60 KB/s

Destination UDP Ports

#	Key	Port	Name	Total		Max	Avg
01		5060	SIP (Session Initiation Protocol)	83.64 MB	52.48 %	2.67 KB/s	968.02 B/s
02		6500	N/A	963.92 KB	0.60 %	1.26 KB/s	11.16 B/s
03		5080	N/A	949.54 KB	0.60 %	461.59 B/s	10.99 B/s
04		443	N/A	924.20 KB	0.58 %	99.32 B/s	10.70 B/s
05		123	NTP (Network Time Protocol)	904.46 KB	0.57 %	62.52 B/s	10.47 B/s
06		3702	WS-Discovery	838.94 KB	0.53 %	268.93 B/s	9.71 B/s
07		5070	VTSAS (VersaTrans Server Agent Service)	695.34 KB	0.44 %	461.99 B/s	8.05 B/s
08		500	ISAKMP	690.84 KB	0.43 %	74.59 B/s	8.00 B/s
09		65476	N/A	633.86 KB	0.40 %	417.08 B/s	7.34 B/s
10		161	SNMP (Simple Network Management Protocol)	597.06 KB	0.37 %	64.44 B/s	6.91 B/s
11	---	1900	SSDP	572.56 KB	0.36 %	58.93 B/s	6.63 B/s
12	---	53	DNS (Domain Name System)	483.34 KB	0.30 %	85.15 B/s	5.59 B/s
13	---	5090	N/A	441.76 KB	0.28 %	440.20 B/s	5.11 B/s
14	---	5062	N/A	425.13 KB	0.27 %	457.64 B/s	4.92 B/s
15	---	5061	SIP over TLS	417.63 KB	0.26 %	455.15 B/s	4.83 B/s
16	---	5182	N/A	400.73 KB	0.25 %	452.59 B/s	4.64 B/s
17	---	6560	N/A	370.93 KB	0.23 %	1.24 KB/s	4.29 B/s
18	---	50600	N/A	352.53 KB	0.22 %	439.08 B/s	4.08 B/s
19	---	55600	N/A	350.13 KB	0.22 %	427.36 B/s	4.05 B/s
20	---	5063	N/A	277.63 KB	0.17 %	290.65 B/s	3.21 B/s
21	---	4092	N/A	276.91 KB	0.17 %	460.93 B/s	3.20 B/s
22	---	4220	N/A	276.83 KB	0.17 %	337.67 B/s	3.20 B/s
23	---	4592	N/A	275.72 KB	0.17 %	457.51 B/s	3.19 B/s
24	---	5066	STANAG-5066-SUBNET-INTF	275.00 KB	0.17 %	412.21 B/s	3.18 B/s
25	---	5000	N/A	273.88 KB	0.17 %	462.47 B/s	3.17 B/s
26	---	5980	N/A	269.00 KB	0.17 %	234.11 B/s	3.11 B/s
27	---	3396	N/A	265.78 KB	0.17 %	443.84 B/s	3.08 B/s
28	---	1809	N/A	265.45 KB	0.17 %	439.52 B/s	3.07 B/s
29	---	2000	N/A	263.22 KB	0.17 %	245.95 B/s	3.05 B/s
30	---	3100	N/A	261.12 KB	0.16 %	441.23 B/s	3.02 B/s
31	---	Others		61.73 MB	38.74 %	95.08 KB/s	714.45 B/s

Source Operating Systems (Windows)

#	Key	Operating System	Total		Max	Avg
01		Windows-2000-RFC1323/Windows-XP-RFC1323	45.84 MB	64.72 %	1.01 KB/s	530.59 B/s
02		Windows-Vista	11.74 MB	16.57 %	607.77 B/s	135.85 B/s
03		Windows-XP-SP1/Windows-2000-SP2+	11.37 MB	16.05 %	468.90 B/s	131.59 B/s
04		Windows-XP-SP1/Windows-2000-SP4	1.40 MB	1.98 %	168.72 B/s	16.25 B/s
05		Windows-2000/Windows-XP	447.64 KB	0.63 %	33.56 B/s	5.18 B/s
06		Windows-XP-SP1/Windows-2000-SP3	27.36 KB	0.04 %	8.50 B/s	0.32 B/s
07		Windows-98-lowTTL	980.72 B	0.00 %	0.68 B/s	0.01 B/s
08		Windows-.NET	367.16 B	0.00 %	0.43 B/s	0.00 B/s
09		Windows-XP-RFC1323	138.84 B	0.00 %	0.16 B/s	0.00 B/s
10		Windows-98	10.29 B	0.00 %	0.02 B/s	0.00 B/s
11		other-Windows	11.00 B	0.00 %	0.03 B/s	0.00 B/s

Source Operating Systems (Other Platforms)

#	Key	Operating System	Total		Max	Avg
01		unknown	3.18 GB	85.71 %	48.42 KB/s	36.81 KB/s
02		Linux	529.14 MB	14.26 %	13.89 KB/s	6.12 KB/s
03		undefined	845.11 KB	0.02 %	169.45 B/s	9.78 B/s
04		Eagle	206.64 KB	0.01 %	11.98 B/s	2.39 B/s
05		NMAP	151.30 KB	0.00 %	7.95 B/s	1.75 B/s
06		SunOS	34.77 KB	0.00 %	13.97 B/s	0.40 B/s
07		NAST	357.63 B	0.00 %	0.46 B/s	0.00 B/s
08		Solaris	304.33 B	0.00 %	0.66 B/s	0.00 B/s
09		OpenBSD	112.00 B	0.00 %	0.37 B/s	0.00 B/s
10		TOPS-20-7	31.81 B	0.00 %	0.07 B/s	0.00 B/s
11		Others	27.50 B	0.00 %	0.07 B/s	0.00 B/s

Observations:

1. Each image above contains a STACK AREA graphic, which means that each data set of the graphic is stacked on top of the previous one.


2. Lists of known TCP/UDP ports and associated service names can be found at the following documents:
   • Port Numbers, from IANA.
   • List of TCP and UDP port numbers, from The Wikipedia.
   • Common Ports, from packetlife.net.


3. A list of known Country Codes can be found at IANA. The country code "XX" stands for network flows that could not be associated with any country code, for example, flows from private networks.
